This is an open-source project bringing unsophisticated billiards physics written in TypeScript to the browser.

## Online Demo

Demos run in all major desktop and mobile browsers and use WebGL

* [Nine ball ⬀](https://billiards.tailuge.workers.dev/?practice=true) make a break and share replay link with friends
* [Three cushion billiards ⬀](https://billiards.tailuge.workers.dev/?ruletype=threecushion&lod=4) the ultimate test of physics and player (average on both counts). You need the [beginner mode ⬀](https://billiards.tailuge.workers.dev/?ruletype=threecushion&practice=true). Try the [practice mode ⬀](https://velikodimov.github.io/billiards/dist/index.html?ruletype=threecushion&practice&drill) to drill specific shots.
* [Sagu ⬀](https://billiards.tailuge.workers.dev/?ruletype=sagu) Korean four-ball carom game. Try [sagu on a 5ft table ⬀](https://billiards.tailuge.workers.dev/?ruletype=sagu&tableSize=5).
* [Snooker ⬀](https://billiards.tailuge.workers.dev/?ruletype=snooker&lod=4&tableSize=12) we await the first 147 submission to the leaderboard.
* [8-Ball ⬀](https://billiards.tailuge.workers.dev/?ruletype=eightball&lod=4) try it in Hi-Res mode!
* Play vs the [Claw ⬀](https://billiards.tailuge.workers.dev/?bot=ClawBreak) and [TheFarJaw ⬀](https://billiards.tailuge.workers.dev/?bot=TheFarJaw).
* Try [two player](https://billiards.tailuge.workers.dev/lobby.html) online lobby using nchan
* Try to get on the leaderboard of highest [breaks](https://scoreboard-tailuge.vercel.app/leaderboard) hosted on Vercel.
* Inspect physics and tweak constants using [diagrams](https://tailuge.github.io/billiards/dist/diagrams/diagrams.html).
* Set up trick shots and [practice ⬀](https://billiards.tailuge.workers.dev/practice.html).
* Tune three cushion [physics ⬀](https://tailuge.github.io/billiards/dist/diagrams/three.html) and [optimise ⬀](https://tailuge.github.io/billiards/dist/fit/viewer.html) parameters
* Parallel [parameter ⬀](https://tailuge.github.io/billiards/dist/fit/common.html) tuning using [Web Workers ⬀](https://tailuge.github.io/billiards/dist/ww.html).
* Three cushion trainer and [sensitivity analysis ⬀](https://velikodimov.github.io/billiards/dist/index.html?ruletype=threecushion&practice&drill) from an excellent [fork ⬀](https://github.com/velikodimov/billiards) of this project.
* Another great spin off extension for [Italian 5 pin](https://gameland.altervista.org/italian_billiards/lobby.html).

## Features

* Backspin, sidespin and cushion bounces well modeled.
* Presentation using WebGL in any modern browser on mobile, linux, mac or windows.
* Record and playback breaks.
* Two player online mode with nchan nginx server.
* Nine ball, snooker, three cushion and Sagu billiards rules.
* Deploys to GitHub Pages, Vercel and Render with GitHub Actions.
* Runs on and was developed mostly on a potato e.g. Raspberry Pi 4.

## Reference material

* Papers on ball mechanics [Han 2005](https://billiards.colostate.edu/physics_articles/Han_paper.pdf)
with important corrections by [Kiefl](https://ekiefl.github.io/2020/04/24/pooltool-theory/#3-han-2005).
* [cushions](https://billiards.colostate.edu/physics_articles/Mathavan_IMechE_2010.pdf), [max spin](https://billiards.colostate.edu/technical_proofs/new/TP_B-17.pdf),
simulation and constants [1](https://savoirs.usherbrooke.ca/bitstream/handle/11143/6598/MR91690.pdf?sequence=1)
[2](http://citeseerx.ist.psu.edu/viewdoc/download?doi=10.1.1.89.4627&rep=rep1&type=pdf)
[3](https://www.researchgate.net/publication/228634093_Bounce_of_a_spinning_ball_near_normal_incidence)
[4](https://billiards.colostate.edu/technical_proofs/new/TP_B-6.pdf)
[5](https://billiards.colostate.edu/faq/physics/physical-properties/)
* 3D graphics uses [three.js](https://threejs.org/docs/index.html#api/math/Vector3)
* Inline [LaTeX](https://www.codecogs.com/eqnedit.php?latex=\dot{a}) editor
for equations in README.md

### Key equations

Based on [Han 2005](https://billiards.colostate.edu/physics_articles/Han_paper.pdf) paper

#### surface velocity

$$\vec{v}_a = \vec{v} + (\vec{up} \times R\vec{\omega})$$

#### sliding motion

$$\dot{v} = -\mu g \frac{\vec{v}_a}{|\vec{v}_a|}$$

$$\dot{\omega} = -\frac{5}{2}\frac{\mu g}{R} \frac{\vec{v}_a}{|\vec{v}_a|}$$

$$\dot{\omega}_z = -\frac{5}{2}\frac{M_z}{mR^2} \text{sgn}(\omega_z)$$

#### rolling motion

$$\dot{v} = -\frac{5}{7}\frac{M_{xy}}{mR} \frac{\vec{up} \times \vec{\omega}}{|\vec{\omega}|}$$

$$\dot{\omega} = -\frac{5}{7}\frac{M_{xy}}{mR^2} \frac{\vec{\omega}}{|\vec{\omega}|}$$

where

$M_{xy} = \frac{7}{5\sqrt{2}} R \mu m g$ , $M_z = \frac{2}{3} \mu m g \rho$

#### collisions

Based on paper by [Alciatore](https://billiards.colostate.edu/technical_proofs/new/TP_A-14.pdf) incorporating throw effect due to the small amount of friction between balls. Figures to prove consistency between the [code](./src/model/physics/collisionthrow.ts) and paper [here](https://tailuge.github.io/billiards/dist/diagrams/mathavan.html).

For ball $a$:

$$\vec{v}_a \leftarrow \vec{v}_a + \frac{J_{\text{normal}}}{m}\hat{n} + \frac{J_{\text{tangential}}}{m}\hat{t}$$

$$\vec{\omega}_a \leftarrow \vec{\omega}_a + \frac{1}{I} (\vec{r}_a \times \vec{J}_{\text{tangential}})$$

For ball $b$:

$$\vec{v}_b \leftarrow \vec{v}_b - \frac{J_{\text{normal}}}{m}\hat{n} - \frac{J_{\text{tangential}}}{m}\hat{t}$$

$$\vec{\omega}_b \leftarrow \vec{\omega}_b + \frac{1}{I} (\vec{r}_b \times \vec{J}_{\text{tangential}})$$

Where:

The relative velocity at the point of contact is computed as:

$$\vec{v}_{\text{rel}} = (\vec{v}_a - \vec{v}_b) + \vec{r}_a \times \vec{\omega}_a - \vec{r}_b \times \vec{\omega}_b$$

$$\vec{v}_{\text{slip}} = \vec{v}_{\text{rel}} - (\vec{v}_{\text{rel}} \cdot \hat{n}) \hat{n}$$

$\vec{r}_a = -R \cdot \hat{n}$ and $\vec{r}_b = R \cdot \hat{n}$

$J_{\text{normal}} = \frac{-(1 + e)v_{\text{rel,normal}}}{(2/m)}$

$J_{\text{tangential}} = \min\left( \frac{\mu J_{\text{normal}}}{v_{\text{rel}}}, \frac{1}{7} \right)(-v_{\text{rel,tangential}})$

$\hat{n}$: normal unit vector along the line of centers.

$\hat{t}$: tangential unit vector perpendicular to $\hat{n}$.

#### cushion bounce

This is based on a paper by [Mathavan](https://billiards.colostate.edu/physics_articles/Mathavan_IMechE_2010.pdf). Many of the [figures](https://tailuge.github.io/billiards/dist/diagrams/mathavan.html) from the paper are recreated to confirm correctness.

Slip velocity at cushion contact point I

$$
ẋ_I = \dot{v_x} + \dot{\omega_y} R \sin \theta - \dot{\omega_z} R \cos \theta \qquad
ẏ'_I = -\dot{v_y} \sin \theta + \dot{\omega_x} R
$$

$$
\phi = \arctan\left(\frac{ẏ'_I}{ẋ_I}\right) \qquad
s = \sqrt{(ẋ_I)^2 + (ẏ'_I)^2}
$$

Slip velocity at table contact point C

$$
ẋ_C = \dot{v_x} - \dot{\omega_y} R \qquad
ẏ_C = \dot{v_y} + \dot{\omega_x} R
$$

$$
\phi' = \arctan\left(\frac{ẏ_C}{ẋ_C}\right) \qquad
s' = \sqrt{(ẋ_C)^2 + (ẏ_C)^2}
$$

Numerical solutions for the centroid velocity of the ball during compression and restitution phases.

$$
(\dot{v_x})_{n+1} - (\dot{v_x})_n = - \frac{1}{M} \left[\mu_w \cos(\phi) + \mu_s \cos(\phi') \cdot (\sin \theta + \mu_w \sin(\phi) \cos \theta)\right] \Delta P_I
$$

$$
(\dot{v_y})_{n+1} - (\dot{v_y})_n  = - \frac{1}{M} \left[ \cos \theta - \mu_w \sin \theta \sin \phi + \mu_s \sin \phi' \cdot \left( \sin \theta + \mu_w \sin \phi \cos \theta \right) \right] \Delta P_I
$$

Numerical solutions for angular velocity of ball

$$
(\dot{\omega_x})_{n+1}−(\dot{\omega_x})_n = -\frac{5}{2MR}[\mu_w \sin(\phi) + \mu_s \sin(\phi') \times (\sin(\theta) + \mu_w \sin(\phi)\cos(\theta))]\Delta P_I
$$

$$
(\dot{\omega_y})_{n+1}−(\dot{\omega_y})_n = -\frac{5}{2MR}[\mu_w \cos(\phi)\sin(\theta) - \mu_s \cos(\phi') \times (\sin(\theta) + \mu_w \sin(\phi)\cos(\theta))]\Delta P_I
$$

$$
(\dot{\omega_z})_{n+1}−(\dot{\omega_z})_n = \frac{5}{2MR}(\mu_w \cos(\phi)\cos(\theta))\Delta P_I
$$

$\theta$ is a constant of the angle of cushion contact above ball centre with $\sin(\theta) = 2/5$. $\mu_s$ is the coefficient of sliding friction between the ball and table surface. $\mu_w$ is the coefficient of sliding friction between the ball and the cushion.

Work done by the normal force at contact point $I$ along the $Z'$-axis which is aligned from the ball centre to I

$$
W_{Z'}^I(P_I^{(n+1)}) = W_{Z'}^I(P_I^{(n)}) + \frac{\Delta P_I}{2} \left( z'_I(P_I^{(n+1)}) + z'_I(P_I^{(n)}) \right)
$$

The ball is assumed to be bouncing in the +y cushion. Compression phase iterates until

$$\dot{v}_y \le 0$$

For the restitution phase the iteration continues until the work done is

$$W_{Z'}^I \ge e_e^2 W_{\text{compression}}$$

Some of the Mathavan equations not supplied by the paper were inferred to bridge gaps for a complete numerical solution.

#### Stronge compliant cushion model

Based on the book *Impact Mechanics* by [Stronge](https://doi.org/10.1017/9781139050227). This analytical model accounts for the compliant nature of cushion deformation and resolves the collision across three slip regimes.

Contact velocity at the cushion contact point:

$$\vec{V}_c = \vec{v} - (\vec{\omega} \times R \hat{n})$$

Regime classification is determined by the ratio $v_{\text{ratio}} = v_{t0} / v_{n0}$ and thresholds involving the friction coefficient $\mu$, restitution $e_n$, and mass-matrix coefficients $\beta$:

| Regime | Condition |
| :--- | :--- |
| Gross slip | $v_{\text{ratio}} > \mu \left( (1 + e_n) \beta_{\text{ratio}} - \frac{\eta^2}{e_n} \right)$ |
| Initial stick | $v_{\text{ratio}} < \mu \eta^2$ |
| Slip-stick-slip | neither of the above |

where $\eta^2$ is derived from the frequency ratio $\omega_t/\omega_n$.

Velocity reconstruction from scalar solver results $v_{nf}$ and $v_{tf}$:

$$\Delta v_n = \frac{v_{nf} - v_{n0}}{\beta_n} , \quad \Delta v_t = \frac{v_{tf} - v_{t0}}{\beta_t}$$

Final updates:

$$\vec{v} \leftarrow \vec{v} + \Delta v_n \hat{n} + \Delta v_t \hat{t}$$
$$\vec{\omega} \leftarrow \vec{\omega} + \frac{mR}{I} (-\hat{n} \times \Delta v_t \hat{t})$$

## Useful commands

### Install

```shell
nvm use v24.11.0
corepack enable
yarn set version 4.9.1
yarn install
yarn build
yarn gltfpack
```

This generates artefacts in /dist for prod deployment (e.g. on github static pages)

### Run

```shell
yarn serve
```

Then open <http://localhost:8080/> in your browser to play

### Test

```shell
yarn test
yarn coverage
```

### Maintain

```shell
yarn deps
yarn upgrade -L
yarn prettify
```

### Two player

```shell
yarn serve
```

then open <http://localhost:8080/multi.html> to see options, message server is public nchan.

## Controls

Use mouse, touch screen or keyboard:

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇦</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇨</kbd> Aim

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">Control</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇦</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇨</kbd> Fine aim

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇧</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇩</kbd> Topspin and backspin

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">Shift</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇦</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">⇨</kbd> Side spin

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">Space</kbd> Hit - hold for more power

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">A</kbd> Toggle aim helper

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">M</kbd> Masse angle

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">O</kbd> Camera view

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">F</kbd> Full screen

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">C</kbd> Chat

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">H</kbd> Help

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">+</kbd>
<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">-</kbd> Camera height

### Mouse

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">scroll</kbd> Shot power

<kbd style="border: 1px solid #aaa; border-radius: 0.2em; padding: 0.1em 0.3em; font-size: 0.85em;">dbl click</kbd> Hit

## Progress snapshots

July 2018

![2018](https://raw.githubusercontent.com/tailuge/billiards/master/dist/images/t1.png)

July 2019

![2019](https://raw.githubusercontent.com/tailuge/billiards/master/dist/images/t2.png)

March 2021

![2021](https://raw.githubusercontent.com/tailuge/billiards/master/dist/images/t3.png)

August 2023 (mobile)

top | aim
:--:|:--:
<kbd>![2023](https://raw.githubusercontent.com/tailuge/billiards/master/dist/images/mobile1.jpg)</kbd> | <kbd>![2023](https://raw.githubusercontent.com/tailuge/billiards/master/dist/images/mobile2.jpg)</kbd>

[![2026](https://img.youtube.com/vi/jGNB_XLTjnU/0.jpg)](https://www.youtube.com/watch?v=jGNB_XLTjnU)

Star History

[![Star History Chart](https://api.star-history.com/svg?repos=tailuge/billiards&type=Date)](https://star-history.com/#tailuge/billiards&Date)

## Licence

This project is open source and licensed under the GNU General Public License - see the [LICENSE](LICENSE) file for details. Contributions welcome.
